Choosing a TV for a small kitchen could previously be a problem due to the lack of space and the complexity of the location near the sink or stove. The Cabinet Door TV takes into account all these nuances and is ideal for installation in such a room. Its location is functional, and technical features allow you not to worry about getting splashes of water or steam on its front surface.
Smart TV in the kitchen will appeal to all family members and guests. This device shows digital TV, but you can also use it to access the Internet, watch online movies, TV series, and download apps.
The front panel of the kitchen Smart TV is completely mirrored. The 23.8-inch Full HD screen with wide viewing angles allows you to comfortably watch TV from anywhere in the kitchen.
Show all
Collapse description
Weight of goods in the package: 13100 g
Package dimensions:
708 x 558 x 150 mm
Specifications
- Mechanisms
- DTC top stay SF NEW PUSH lift system
- Model
- AVS240KS (Mirror)
- Smart TV
- Yes
- Screen Finish
- Magic Mirror
- Frame Material
- Steel
- Screen Material
- Glass
- Screen Size
- 23.8" (61 cm)
- Screen Type
- LED LCD
- Resolution
- Full HD (1920x1080)
- Brightness
- 700 cd/m2
- Aspect Ratio
- 16:9
- Contrast Ratio
- 1000:1 (typ.)
- Colour Depth
- 16.7 million
- Viewing Angle
- 178°/178° (H/V)
- OS
- Android
- OS version
- 11 (AOSP)
- APP
- Google Play Store, Chrome
- CPU
- RTD2843 ARM Cortex-A55 up to 1.1GHz (Quad core)
- GPU
- Mail G31*2-High speed 700MHz
- RAM
- DDR3 1.5G
- Storage
- 8G
- Speakers
- 2 x Internal Speakers (support external BT speaker)
- Output
- 2*5W/8Ohms
- DTV Tuner
- DVBT/T2/C/S/S2/ATSC(support H.264/H.265, Dolby+)
- Analogue Tuner
- Video: NTSC/PAL/PAL-M/PAL-N, Audio: BG/DK/I
- USB Host
- Video, pictures and music from USB flash / HDD
- Supported File Types
- Video: MPEG1/2/4,H.264*,H.265*,WMV*,VC1,VP8,VP9,RM*,AVS*,AVS2.0*,Sorenson,Motion JPEG,H.263,AV1,
Audio: PCM,AMR,LPCM,RA*,MPEG1/2/4,AAC*,WMA*,Dolby AC3*,Dolby EAC3*,Dolby AC4*,Dolby*,MPEG-H,DRA,FLAC,VORBIS,
Image: *.JPG,*.BMP,*PNG,*.GIF,.MPO,.JPS,.PNS
- Wi-Fi
- 2.4G/5G, IEEE 802.11 a/b/g/n/ac ,1T1R, 229.4Mbps,Support Wifi 6
- Ethernet
- RJ45 10/100M auto-identification and DHCP
- Bluetooth
- V2.1+EDR/V3.0/V4.x/V5.0
- TV In / Aerial
- 1 x ICE TYPE TV(75ohm, DVB-T/T2/C/Analogue), 1 x F TYPE TV (S/S2) or 1 x F TYPE(ATSC)
- HDMI Input
- 2 (HDMI1-ARC,HDMI1&2-CEC)
- USB
- 2 (USB 2.0)
- Optical fiber (Digital Audio Out)
- 1
- RJ45
- 1
- Earphone
- 1
- CI slot (CI +)
- 1 (ATSC not available)
- IR pass through
- 1
- DC In (12V)
- 1
- Working Temperature
- 0°C – +50°C
- HDMI-CEC (Anynet) Control
- TV can turn on/off automatically when connected to STB or Smart TV box by HDMI
- HDMI-ARC
- Audio Return Channel,TV can return the audio to Amplifier or ARC device
- Product Size
- 23.39" *17.91" *1.97" (WxHxD)
- Product Weight
- 18.7 lb
- Shipping Size
- 27.87" *5.91" *21.97" (WxHxD)
- Shipping Weight
- 28.9 lb
- Wall Mount Compatibility (on-wall installation)
- Vesa (100 x 100 mm)
- Flip Up Lift System with Handle
- Blum HK29 (with 20S4200 front fixing bracket)
Blum HK TOP29 (22K2910 with pre-mounted screws + 20S4200 front fixing bracket)
Kessebohmer FREEflap forte-F
Hafele Free Flap 3.15 F
DTC TOP STAY SF, SF00AH, power factor 3200-9000 (h250-720). Catalog number white caps - SF00AH02A
- Flip Up Lift System with Push to Open (without Handle)
- Blum HK29T (with 20S4200 front fixing bracket) + Tip-On (956A1006)
Blum HK TOP29T (22K2910T with pre-mounted screws + 20S4200 front fixing bracket + 956A1004 Tip-On set)
Kessebohmer FREEflap forte-F + Push to Open 26-48N
Hafele Free Flap 3.15 F + Door catch 26-48N
- Slide Up Lift System with Handle
- Blum HL27/38 (with 20S4200 front fixing bracket)
Kessebohmer FREEslide Q3us + 2719180038 (Cross Bar 600mm)
Hafele Free up Q3us + 372.33.692 Crossbar alu.
- Flip Up Lift System with motorized drive
- Blum HK TOP SERVO-DRIVE SET 23KA000 + Blum plug-in transformer 12W
Kessebohmer eTouch drive for FREEflap (27 2055 7035) + cover set eTouch FREEflap gray (27 1972 7035) + Set of lifts FREEflap mini, series 107 С gr (left, right) cover gray (27 1663 7035)
- Slide Up Lift System with motorized drive
- Blum HK/HL SERVO-DRIVE SET 21FA000 + Blum plug-in transformer 12W
Kessebohmer eTouch drive for fold, slide/swing (27 2054 7035) + cover set eTouch FREEslide gray (27 1970 7035) + lever arm for FreeSlide Q - Н380-500 mm (27 1966 0006) + cross bar for façade 600mm (27 1918 0038)
- Important Note
- Lift Systems are not included — please purchase locally!
Certifications and Standards
- CE, ROHS, EAC
- Yes
- Mains Power
- AC 100-240V (DC 12V/4.25A adaptor)
- Power Consumption
- 23 W
- Standby Power Consumption
- 0.23 W
- Warranty
- 1 Year (manufacturing defects in materials and workmanship)
- Remote Control with Wall Holder
- 1 pcs (IP66 waterproof, protection against water jets — don't immerse in water!)
- Air Mouse (BT voice remote control)
- 1 pcs (Non-Waterproof)
- Power Adapter
- 1 pcs
- Power cable
- 1 pcs
- Cable Fixation Ties
- 4 pcs
- Silicone damper
- 2 pcs
- Velcro
- 2 pcs*15cm
- Screws for VESA and Blum / Kessebohmer / Hafele Mounts
- 1 set
- Installation Guide and FAQ
- 1 set
